AC Touch Panel Zigbee+RF traic dimmer

1.  Support control traditional incandescent lamps, halogen lamps, triac dimmable LED lamps.

2.  Support set up min brightness.

3.  Trailing edge phase-cut dimming.

4.  Temperature detecting switch,with overheat protection and automatic recoverfunction.

5.  Overloading protection,automatic power limit.

6.  Product follow zigbee 3.0 standard protocol.

7.  Can be installed in a standard 86*86 wall junction box,VO class anti-fire case.

Category:

Description









  Item AC Touch Panel Zigbee+2.4G Triac Dimmer
  Model  TW02Z
  Input Voltage 100-240V~ 50/60Hz
  Output Voltage 100-240V
Output Current 1.4A
 Output Power 154W@110V 308W@220V
  Dim Method  Zigbee3.0+2.4G
2.4G RF Control Distance 30m
  Working Temperature  -20~40℃
Wireless Technology  Zigbee 802.15.4
  Warranty  3 years
  Size  86*86*48mm
