Zigbee3.0 CCT LED Controller

Home/LED Controller/Zigbee LED Controller/Zigbee3.0 CCT LED Controller

Zigbee3.0 CCT LED Controller

1.It’s used for controlling dual white LED strip lights.

2,Support Philips Hue and Samsung Smartthings Bridge control.

3.Compatible with Amazon Alexa & Google Assistant(Zigbee Gateway is needed).

4.Support group control, device sharing,timing,plan and wake up function etc.

5.Three Year Warranty

Description

Our Zigbee3.0 CCT LED controller is suitable for dual white LED strip lights. It is so far the most advanced controller, which integrates color temperature management and dimming function.

Zigbee3.0 CCT LED controller Features:

cct LED dimmer zigbee

2.Connect to LED strip

dual white led dimmer zigbee



3.Connect to Smartphone

You must link the Tuya Zigbee 3.0 Gateway first to the smartphone, then add the zigbee controller to zigbee gateway for smartphone control.

(1). How to connect zigbee gateway to smartphone.(Note: All Tuya Zigbee 3.0 gateway in market can works on our Zigbee controller; Here we use our wireless Zigbee 3.0 gateway for example).

First, Power the zigbee gateway, and long press the “SET” button until the red indicating lamp blinking.



Second, when the red indicating lamp blink, open the Smart Life APP,and press “Add Device”.It will discover the new device automatically, then Press “Add” to complete the linking.

(2).Add the Zigbee controller to the linked zigbee gateway.

First, Power the controller, Short press on “SET”button for 4 times on the controller or switch ON-OFF the power 4 times(ON-OFF-ON-OFF-ON-OFF-ON), when the white light blink 10-15 seconds slowly means the controller come into smart link mode. (Note: Note: when the controller on the smart link mode, please finish the linking within 3 minutes, after 3 minutes, the controller will stop smart link mode, you need to do the above steps again).

Second, Press “Add new devices” on the APP, it will automatically find the zigbee device, then complete the linking. Added device will be displayed on the homepage after added successfully, then Click device you want to control to enter the control interface.

  Item   C02Z
  Brand   Laimi
  Input Voltage   DC5V/DC12V/DC24V
  Output   7.5A/Channel
  Total Output Max 15A
  Certification   CE/RoHS
  Controller Type   APP control/Voice Control
  Control Method   Zigbee control
  Working Temperature   -20~60℃
  Application   Smart     lighting/Smart     home
  APP Name   Tuya Smart Life
  System    iOS/Android
  Warranty   3 years
  Material    V-0 Anti-fire PC
  Size   74.5*36.5*16.5mm
  Weight   20g
